Description
Yamaha DTX10K-X Real Wood
Overview
DTX flagship model that boasts the beauty of real drums
The DTX10 Series is the flagship of the DTX lineup, combining the functionality of electronic drums with the sheer beauty of their acoustic counterparts.
Featuring real drum sounds and real-room ambience recorded in world-renowned studios, intuitive playability, inspiring feel and expressiveness, and real birch shells finished like Yamaha acoustic drums, the DTX10 Series was born from Yamaha’s long history of drum craftsmanship.
- Faithfully reproduces real drum sounds and real-room ambience recorded in world-renowned studios
- AMBIENCE, COMP and EFFECT Kit Modifier knobs allow you to create your own unique sounds
- LED rotary faders allow intuitive, accurate and fast control
- Yamaha original TCS heads for snare and toms provide natural feel and rebound
- Beautiful wood shells built and finished at Yamaha acoustic drum factories
- Snare pad and ride cymbal equipped with hit point detection
- Individual outputs, AUX inputs, USB audio/MIDI connectivity
- Professional Yamaha system hardware for stands and racks
Real sounds that drive the drummer
No compromise has been made in recording the sound of the instruments themselves. DTX-PROX sounds have been fine-tuned to naturally follow the drummer’s performance and allow for maximum expression.
The acoustic drum sounds built into the DTX-PROX are real recordings from world-class studios, including both direct sound and natural room ambience.
Performances by leading Yamaha artists were recorded and mixed by expert engineers to capture every detail from attack to decay. Pads are carefully matched to the module for excellent expressive capability.
Intuitive playability that inspires creativity
The Kit Modifier and LED rotary fader system on the DTX-PROX offer limitless creative possibilities.
The three KIT MODIFIER knobs—AMBIENCE, COMPRESSION and EFFECT—condense decades of Yamaha sound design expertise.
The seven LED rotary faders allow control of instrument parameters, with six presets and fourteen sub-presets. They can also control external devices and DAWs.
Yamaha TCS
Yamaha TCS (Textured Cellular Silicone) heads provide realistic hardness, rebound and stick feel. Their surface prevents stick sliding and maintains consistent feel over time. The snare includes hit point detection.
Superbly playable
Yamaha studied drum behavior extensively to reproduce authentic response. Professional drummers worldwide evaluated the DTX-PROX to refine its expressive capabilities.
Original TCS heads
TCS heads use silicone foam with air bubbles for firmness, rebound and reduced impact noise. A floating structure prevents vibration transfer, improving sensitivity and quietness.
Live Set function instantly recalls settings
The Live Set function allows instant recall of kits, tempos, audio files and click settings—ideal for live performance and streaming.
Connect to Bluetooth and record performances to USB memory
Bluetooth allows wireless playback from smart devices. USB memory can record Bluetooth, AUX, USB audio and your own drum performance.
Professional-grade headphone amp
The DTX-PROX includes a high-precision, low-noise, high-power headphone amplifier for immersive monitoring.
Connections for every possible application
Includes 8 individual outputs, dual AUX IN, multiple headphone outputs, and USB audio/MIDI connectivity.
An extensive range of training functions
Includes programmable metronome, recorder, 10 training modes and 37 preset songs.
Includes Cubase AI
Comes with a download code for Cubase AI for recording, editing and mixing.
Specs
Pad Sets
| Snare | XP125SD-X (12-inch TCS pad with 2-zone) | |
|---|---|---|
| Tom Pad | XP105T-X (10-inch TCS pad with 2-zone) | |
| Floor Tom Pad | XP105T-X (10-inch TCS pad with 2-zone) | |
| Kick Pad | KP90 (7.5-inch rubber pad with multi-layer cushion) | |
| Hi-Hat Pad | RHH135 (13-inch pad with 2-zone) | |
| Crash Cymbal 1 | PCY135 (13-inch pad with 3-zone) | |
| Crash Cymbal 2 | PCY135 (13-inch pad with 3-zone) | |
| Ride Cymbal | PCY155 (15-inch pad with 3-zone) | |
| Hi-Hat Stand | HS650A | |
| Snare Stand | SS662 (Snare Stand for 12″) | |
| Footprint | 1,100 mm x 1,500 mm | |
| Rack System | RS10-HXR | |
| Weight | 45.88 kg | |
| Dimensions | Width | 342 mm (13-7/16 in) |
|---|---|---|
| Height | 196 mm (7-11/16 in) | |
| Depth | 66 mm (2-5/8 in) | |
| Weight | 2 kg (4 lbs, 7 oz) | |
| Maximum Polyphony | 256 notes | |
| Effects | For each Inst: EQ / Comp / Transient / Insertion (*1), For each Kit: Ambience / Effect 1 / Effect 2 and Master Comp / Master Effect, For overall: Master EQ / Phones EQ (*1) Insertion effects can be used only for specific Inst. | |
| Drum Kits | Preset: 70 Kits, User: 200 Kits | |
| Voices | 733 | |
| Click Sets | 30 | |
| Tempo | 30 to 300 BPM, Tap Tempo supported. Voice guide | |
| Time Signatures | 1/4 to 16/4, 1/8 to 16/8, and 1/16 to 16/16 | |
| Subdivisions | Accents, quarter notes, eighth notes, sixteenth notes, and eight-note triplets | |
| Others | Individual click volume control, WAV import, timer | |
| Types | 10 | |
| Songs | Preset: 37 songs, User: 1 song | |
| Import Limit | 1,000 files | |
| Maximum Loadable Sample Time | 50 minutes 40 seconds (44.1 kHz, 16 bit, mono), 25 minutes 20 seconds (44.1 kHz, 16 bit, stereo) | |
| Sample Format | WAV | |
| Recording Time | Internal Memory | Maximum of 90 seconds |
| USB Flash Drive | Maximum of 90 minutes per file | |
| Format | Record/playback: WAV (44.1 kHz, 16 bit, stereo) | |
| Connectors | DC IN | DC IN (+12V) |
| Headphones | Headphones (standard stereo phone jack ×1, stereo mini jack ×1) | |
| AUX IN | AUX IN (stereo mini jack ×1, stereo standard phone jack ×1) | |
| Output | OUTPUT L/MONO, R (standard phone jack, one for each), INDIVIDUAL OUTPUT 1/2, 3/4, 5/6, 7/8 (stereo standard phone jack, one for each) | |
| USB | USB TO DEVICE, USB TO HOST | |
| MIDI | MIDI OUT ×1, MIDI IN ×1 | |
| Trigger Input | Trigger input jack ×10 (standard stereo phone jack, not including the HI-HAT CONTROL jack. 1, 14 for all types of pads; 2, 4, 6 for 2-zone; 8, 9, 10 for 3-zone; 11 dedicated for hi-hat pad/controller; 12 for kick, 2-zone) *If other pad is connected to each of the above terminals, it will operate as a 1-zone pad. *Maximum of 14 pads can be connected (when Y-cable is used) | |
| Bluetooth | Audio (varies by country) | |
| Display | Full Dot LCD (128×64 dot) | |
